Axis T8524 POE+ NETWORK SWITCH
Op voorraad: 2 stuks
AXIS T8524 PoE+ Network Switch is an easy to install 24-port managed Gigabit switch - a perfect complement to Axis’ recorders to further simplify setup and installation of surveillance systems.
- Voor 16:00 besteld, snel verzonden
- Gratis verzending in Nederland vanaf € 150
- 14 dagen bedenktijd en retour
- Persoonlijk advies van onze specialisten
AXIS T8524 PoE+ Network Switch is an easy to install 24-port managed Gigabit switch - a perfect complement to Axis’ recorders to further simplify setup and installation of surveillance systems. AXIS T8524 comes with an integrated DHCP server for automatic assignment of IP addresses and discovery of connected Axis devices. The intuitive administrator interface offers a graphic topology for easy overview of all devices in the system with information about connected devices and status. The high PoE power output allows for connection of up to 24 PoE cameras.
leaflet ( Engels ) Product Brochure
manual pdf ( Engels ) User manual
leaflet ( Frans )
manual pdf ( Frans )
leaflet ( Engels ) Product Brochure
manual pdf ( Engels ) User manual
Specifications
| Jumbo frames | 9216 |
|---|---|
| Jumbo frames support | Yes |
| MAC address table | 8000 entries |
| Switching capacity | 52 Gbit/s |
| Throughput | 38,7 Mpps |
| Housing material | Metal |
| Product colour | Black |
| Rack mounting | Yes |
| ARP inspection | Yes |
| Quality of Service (QoS) support | Yes |
| Switch type | Managed |
| Networking standards | IEEE 802.1x, IEEE 802.3at |
| Virtual LAN features | Private VLAN |
| VLAN support | Yes |
| Operating relative humidity (H-H) | 10 - 90 procent |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 5 - 95 procent |
| Storage temperature (T-T) | -10 - 70 °C |
| Cables included | AC |
| Rack mount kit | Yes |
| User guide | Yes |
| Rubber feet | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 2 |
| Installed SFP modules quantity | 2 |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Surge protection | Yes |
| Surge protection voltage | 6 kV |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 370 W |
| Access Control List (ACL) | Yes |
| BPDU filtering/protection | Yes |
| DHCP features | DHCP server, DHCP snooping |
| ICMP attack prevention | Yes |
| IGMP snooping | Yes |
| Password protection | Yes |
| Security algorithms | HTTPS, SNMP, SNMPv3 |
| SSH/SSL support | Yes |
| Warranty | 5 years |
| Merk | Axis |
|---|---|
| Part number (MPN) | 01192-002 |
| EAN | 7331021061866 |
