IBM N2115 SAS/SATA HBA for IBM System x
Leverbaar op bestelling
The N2115 SAS/SATA HBA for IBM System x is an ideal solution for System x servers requiring high-speed internal storage connectivity. This 8-port host bus adapter supports direct attach to SAS and SATA internal hard disk drives and solid-state drives (SSDs).
- Voor 16:00 besteld, snel verzonden
- Gratis verzending in Nederland vanaf € 150
- 14 dagen bedenktijd en retour
- Persoonlijk advies van onze specialisten
The N2115 SAS/SATA HBA for IBM System x is an ideal solution for System x servers requiring high-speed internal storage connectivity. This 8-port host bus adapter supports direct attach to SAS and SATA internal hard disk drives and solid-state drives (SSDs).
The N2125 SAS/SATA HBA for IBM System x is a low-cost, high-performance 8-port host bus adapter perfect for high-performance connectivity between System x servers and external storage JBOD, Tape, and RAIDed units.
With low-profile form factor designs, the N2115 SAS/SATA HBA for IBM System x and the N2125 SAS/SATA HBA for IBM System x offer two (x4) internal mini-SAS connectors and two (x4) external mini-SAS connectors, respectively. They are based on LSI 2308 6 Gbps SAS IO controller; both provide eight lanes of 6 Gbps SAS and eight lanes of PCIe 3.0 to eliminate data bottlenecks and provide high data transfer rates for medium-to-large capacity server storage applications.
Specifications
| Certification | BSMI, C-tick, CE, cUL, EMC, FCC, IEC60950, KC, TUV, UL, VCCI |
|---|---|
| Internal | Yes |
| Purpose | Server |
| Chipset | LSI SAS2308 |
| Data transfer rate (max) | 6 Gbit/s |
| Operating relative humidity (H-H) | 8 - 93 procent |
| Operating temperature (T-T) | 5 - 40 °C |
| User guide | Yes |
| Connector(s) | 8 x SAS+SATA, 2 x mini-SAS |
| Host interface | PCIe |
| Output interface | SAS, SATA |
| Linux operating systems supported | Yes |
| Windows operating systems supported | Yes |
| Warranty | 1 year |
| Merk | IBM |
|---|---|
| Part number (MPN) | 46C8988-RFB |
