Intel Intel® Xeon® Processor E5-2620 v3 (15M Cache, 2.40 GHz)

Leverbaar op bestelling

€ 11,95
Op voorraad
SKU
CM8064401831400-RFB

With the Intel® Xeon® processor E5-2600 v3 and Intel® Xeon® E5-1600 v3 product families at the heart of an agile, efficient data center, your organization can respond rapidly to changing business demands, protect data from cybercriminals and streamline data center operations.

  • Voor 16:00 besteld, snel verzonden
  • Gratis verzending in Nederland vanaf € 150
  • 14 dagen bedenktijd en retour
  • Persoonlijk advies van onze specialisten

With the Intel® Xeon® processor E5-2600 v3 and Intel® Xeon® E5-1600 v3 product families at the heart of an agile, efficient data center, your organization can respond rapidly to changing business demands, protect data from cybercriminals and streamline data center operations.

**A New Way to Think About the Data Center**

Now designed for compute, storage, and networking to work better together, the latest Intel® Xeon® processor can help you meet today’s challenges while laying the groundwork for tomorrow’s fully-orchestrated data center.

- Deliver more automation capabilities for higher-performing, more secure clouds

- Solve increasing demands for storage and quickly crunch through complex data analytics problems

- Meet the speed of execution expected today

- Operate a more cost-effective, energy-efficient data center

- Measure and monitor.

**Responsive Performance, Remarkable Energy Efficiency**

The latest members of the Intel® Xeon® processor E5 family deliver the best combination of performance, built-in capabilities, and cost-effectiveness to address technical computing challenges, enable cloud deployments, accelerate processor performance for peak loads, deliver intelligent storage or power data analytics. In comparison to previous generation processors you get:

- Up to 3x more performance

- The world's most energy efficient server

- Up to 1.9x more performance with Intel® AVX2

- Up to 1.7x increased virtual machine density

- Up to 1.4x increased memory bandwidth with DDR4.

**Streamline Your Path to Private Cloud Services Delivery**

Built-in virtualization delivers faster performance for core virtualization processes and improves the quality and control of services.

- Improved application performance, live migration, provisioning, dynamic load balancing, and disaster recovery.

- Greater service quality and utilization by monitoring individual virtual machines (VMs) in cache and addressing “noisy neighbor” issues.

- Enabling ultra-high isolation for usages such as financial services.

**A Foundation for Trust and Security**

Improve your ability to safeguard your data and infrastructure with foundational, hardware-assisted security capabilities.

- Encourage pervasive encryption by reducing associated performance penalties.

- Deploy a wide range of security applications with faster, higher-quality cryptographic keys and certificates.

- Protect your operating system by increasing security against malware, denial-of-service (DoS), privilege escalation, and platform surface attacks.

- Protect against attacks against the hypervisor, BIOS, firmware, and other prelaunch software components and gain visibility into system security to strengthen IT compliance.

Specifications

Commodity Classification Automated Tracking System (CCATS)G077159
CPU configuration (max)2
Embedded options availableYes
Execute Disable BitYes
Export Control Classification Number (ECCN)5A992C
Idle StatesYes
Market segmentServer
Maximum number of PCI Express lanes40
PCI Express CEM revision3.0
PCI Express configurations1x16, 1x4, 1x8
PCI Express slots version3.0
Physical Address Extension (PAE)46 Bit
Scalability2S
Supported instruction setsAVX 2.0
Thermal Monitoring TechnologiesYes
On-board graphics cardNo
ECCYes
Maximum internal memory supported by processor768 GB
Memory channelsQuad-channel
Memory clock speeds supported by processor1600, 1866
Memory types supported by processorDDR4-SDRAM
Tcase72,6 °C
Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
Maximum internal memory786432 MB
BoxNo
Bus typeQPI
Component forServer/workstation
Cooler includedNo
Memory bandwidth supported by processor (max)59 GB/s
Number of QPI links2
Package typeTray
Processor ARK ID83352
Processor base frequency2,4 GHz
Processor boost frequency3,2 GHz
Processor cache15 MB
Processor cache typeSmart Cache
Processor codenameHaswell
Processor cores6
Processor familyIntel Xeon E5 v3
Processor frequency2,4 GHz
Processor lithography22 nm
Processor manufacturerIntel
Processor modelE5-2620V3
Processor operating modes64-bit
Processor seriesIntel Xeon E5-2600 v3
Processor socketLGA 2011-v3
Processor threads12
SteppingR2
System bus rate8 GT/s
Thermal Design Power (TDP)85 W
VID Voltage Range0.65 - 1.3 V
Conflict-Free processorNo
Enhanced Intel SpeedStep TechnologyYes
Intel 64Yes
Intel Demand Based SwitchingYes
Intel Enhanced Halt StateYes
Intel Flex Memory AccessNo
Intel Identity Protection Technology version0.00
Intel Secure Key Technology version1.00
Intel Trusted Execution TechnologyYes
Intel TSX-NINo
Intel TSX-NI version0.00
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)No
Intel® OS GuardYes
Intel® Secure KeyYes
Intel® Transactional Synchronization ExtensionsNo
Intel® Turbo Boost Technology2.0
Intel® Turbo Boost Technology 2.0 frequency3,2 GHz
Intel® vPro™ Platform EligibilityYes
Intel® vPro™ TechnologyYes
Bus bandwidth8
Bus speed8 GT/s
Bus type unitsGT/s
End of servicing updates dateFriday, December 31, 2021
Last change63903513
Launch dateQ3'14
Maximum memory768 GB
Processor brand nameIntel Xeon v2
Product familyIntel Xeon Processor E5 v3 Family
Product typeProcessor
Servicing statusEnd of Servicing Updates
StatusLaunched
Supported memory typesDDR4-SDRAM
Processor package size52.5mm x 45mm mm
Warranty1 year
Meer informatie
MerkIntel
Part number (MPN)CM8064401831400-RFB
